美孚SHC齒輪系列?哦
非公路設備用特殊性能齒輪油
產品描述
美孚公司?系列潤滑油是性能卓越的齒輪哦重型齒輪油用于潤滑封閉以及滑動與滾動在非公路設備受到的沖擊和重載軸承傳動。他們的目的是提供卓越的服務,在設備保護,石油生活和無問題運作,有助于提高客戶的生產力。這些科學設計的合成潤滑油是由具有優異的氧化和熱性能和優良的低溫流動性的合成基礎油配制而成的。一個天然的高粘度指數和一個獨特的添加劑系統的組合,有助于使這些產品提供卓越的性能,在惡劣的高溫和低溫操作條件。合成基液的性質也有助于產品的優異的低溫性能。他們提供卓越的保護:在重載齒輪箱齒輪膠合。合成基礎油本身就具有低牽引性能,導致不合格的表面如齒輪和滾動軸承負荷區的低流體摩擦。減少流體摩擦產生較低的工作溫度和提高齒輪效率。美孚SHC齒輪哦系列粘度范圍從ISO VG 320到680是可行的,并且是產品的選擇主要的原始設備制造商和客戶的要求關閉高速公路的應用。
Mobil SHC? Gear OH Series
Exceptional Performance Gear Oils for Off-Highway Equipment
Product Description
The Mobil SHC? Gear OH Series lubricants are exceptional performance heavy-duty gear oils primarily designed to lubricate enclosed gearing as well as plain and rolling element bearings in off-highway equipment subject to shock and heavy loading. They are designed to provide outstanding service in terms of equipment protection, oil life, and problem-free operation helping to enable increased customer productivity. These scientifically engineered synthetic lubricants are formulated from synthetic base fluids that have exceptional oxidation and thermal properties and excellent low temperature fluidity. The combination of a naturally high viscosity index and a unique additive system helps enable these products to provide outstanding performance under severe high and low temperature operating conditions. The nature of the synthetic base fluids also contributes to the products' excellent low temperature performance. They deliver outstanding gear scuffing protection in heavily loaded gearboxes. The synthetic base stocks have inherently low traction properties that result in low fluid friction in the load zone of non-conforming surfaces such as gears and rolling element bearings. Reduced fluid friction produces lower operating temperatures and improved gear efficiency. The Mobil SHC Gear OH Series is available in viscosity range from ISO VG 320 to 680, and are the products of choice for key OEMs and customers for demanding off-highway applications.
Features and Benefits
The Mobil SHC Gear OH Series of lubricants is a member of the Mobil SHC brand of products. These scientifically engineered synthetic lubricants symbolize the continuing commitment to using advanced technology to provide outstanding lubricant products. The Mobil SHC Gear OH Series of lubricants provide benefits not possible with mineral stocks, particularly under extreme high and low temperature operating conditions.
Our formulation scientists have used a proprietary additive combination that fortifies the base fluids to provide excellent EP and anti-wear performance that protects equipment, even under heavy load situations. Specific features and potential benefits for the Mobil SHC Gear OH Series of lubricants include:
Features
|
Advantages and Potential Benefits
|
Outstanding load-carrying and antiwear properties
|
Helps extend gear life and reduce maintenance costs
|
High viscosity index
|
Trouble-free operation over a wide temperature range particularly at extremely low temperatures.
|
Low traction properties
|
Helps improve gear efficiency and lower operating temperatures lead to lower operating costs
|
Outstanding thermal/oxidation resistance and long product life
|
Helps reduce lubricant consumption, which can reduce product and change-out costs
|
Light color
|
Helps minimize the need for gear cleaning prior to inspections, which can reduce maintenance costs
|
Applications
Application Considerations: While the Mobil SHC Gear OH Series are compatible with mineral oil based products, admixture may detract from their performance. Consequently it is recommended that before changing a system to one of the Mobil SHC Gear OH Series, it should be thoroughly cleaned out and flushed to achieve the maximum performance benefits.
Mobil SHC Gear OH Series oils are recommended for many types of enclosed steel-on-steel gear drives. They are suitable for both circulation and splash lubrication systems. Mobil SHC Gear OH Series is available in viscosities from ISO 320 to ISO 680, providing the right lubrication option for low temperature applications where pour points as low as -45°C (-49°F) are required to high temperature applications where operating temperatures of 121oC (250oF) are encountered. They are particularly recommended for lubricating gear sets in off-highway applications such as those found in mining, where heavy or shock loads and boundary lubrication conditions may prevail.
Typical Properties
Mobil SHC Gear OH
|
320
|
460
|
680
|
ISO Viscosity Grade ISO 3448
|
320
|
460
|
680
|
Kinematic Viscosity, ASTM D 445
|
|
|
|
cSt @ 40o C
|
320
|
460
|
680
|
cSt @ 100o C
|
40.1
|
54.9
|
76.1
|
Viscosity Index, ASTM D 2270
|
178
|
186
|
193
|
ASTM Color, ASTM D 1500
|
L0.5
|
L0.5
|
L0.5
|
Pour Point, oC, ASTM D 5950
|
-45
|
-42
|
-39
|
Brookfield @-20o F (-28o C), ASTM D 2983
|
60,000
|
110,000
|
170,000
|
Total Acid Number, mg KOH/g, ASTM D 665
|
0.6
|
0.6
|
0.6
|
Density @15.6o C kg/l, ASTM D 4052
|
0.86
|
0.86
|
0.86
|
Flash Point COC, oC, ASTM D 92
|
233
|
233
|
233
|
4-Ball EP Teat, ASTM D 2783: Weld load, Kg
|
250
|
250
|
250
|
4-Ball EP Teat, ASTM D 2783: Load Wear Index, Kgf
|
48
|
48
|
48
|
FZG Gear Scuffing (A/8.3/90), ISO 14635-1 mod Failure Stage
|
>13
|
>13
|
>13
|
Copper Corrosion, ASTM D130, 3 hrs @ 100o C
|
1B
|
1B
|
1B
|
Foaming Characteristics, ASTM D 892, Seq. I, II, III, Tendency/Stability, ml/ml
|
0/0, 0/0, 0/0
|
0/0, 0/0, 0/0
|
0/0, 0/0, 0/0
|
Rust Protection, ASTM D 665B, Synthetic Sea Water
|
Pass
|
Pass
|
Pass
|
 |
