Mobil SHC 22M及46M
齒輪油
產品描述
Mobil SHC 22M及46M是最高性能的超高粘度合成潤滑油,專為使用在重載、低速齒輪在邊界潤滑條件往往占上風。它們是由合成的基礎股,具有顯著的低溫流動性,即使在這樣高的粘度等級。這些超高粘度的產品可以泵在相對長的距離,并使用標準的噴霧應用設備。一個天然的高粘度指數和一個獨特的添加劑系統的組合,使產品具有特殊的熱/氧化性能,并提供卓越的性能,在惡劣的高溫和低溫的工作條件,即使非常緩慢的移動齒輪。添加劑配方還提供了優異的極壓和抗磨性能和防銹蝕。
Mobil SHC 22M及46M超過齒輪-冬季和夏季成績間歇潤滑法爾克公司的最低粘度要求,分別。這些成績也符合AGMA潤滑劑數14R和15R,粘度的要求,雖然他們沒有殘留的潤滑劑,但領先的綜合產品。Mobil SHC 22M及46M不含有任何溶劑或?yàn)r青類基礎油。

Mobilgear SHC 22M and 46M
Gear Oils
Product Description
Mobilgear SHC 22M and 46M are supreme performance ultra high viscosity synthetic lubricants designed specifically for use in heavily loaded, low speed gears where boundary lubrication conditions often prevail. They are formulated from synthetic base stocks, which have remarkable low-temperature fluidity, even at such high viscosity grades. These ultra high viscosity products can be pumped over relatively long distances and use standard spray application equipment. The combination of a naturally high viscosity index and a unique additive system gives the products exceptional thermal/oxidative properties and provides outstanding performance under severe high and low temperature operating conditions even with very slow moving gears. The additive formulation also provides excellent EP and anti-wear performance and rust and corrosion inhibition.
Mobilgear SHC 22M and 46M exceed Falk Corporation's minimum viscosity requirements for intermittent lubrication of gears - winter and summer grades, respectively. These grades also meet the viscosity requirements for AGMA lubricant numbers 14R and 15R, respectively, although they are not residual lubricants, but are leading edge synthetic products. Mobilgear SHC 22M and 46M do not contain any solvent or any asphaltic-type base oil.
Features and Benefits
Mobilgear SHC 22M and 46M lubricants are leading members of the Mobil SHC brand of products that are world-renowned for their innovation and performance. These scientifically engineered synthetic lubricants symbolize the continuing commitment to using advanced technology to provide outstanding lubricant products. Mobilgear SHC 22M and 46M provide benefits not possible with mineral stocks, particularly under extreme high and low temperature operating conditions, and deliver performance features and customer benefits.
Our formulation scientists have used innovative combinations of base oils plus a proprietary additive combination that fortifies the base oils to provide excellent EP and anti-wear performance, even in shock load situations. The resulting finished products have shown exceptional performance in OEM evaluations, customer field tests and commercial use. These ultra high viscosity products are particularly effective in low-speed, high load, high temperature situations and provide excellent gear and bearing protection, longer oil life and excellent all-round service compared with conventional products.
Specific features and potential benefits for the Mobilgear SHC 22M and 46M lubricants include:
Features
|
Advantages and Potential Benefits
|
Thick EHL fluid film formation and selected additives provide outstanding load-carrying, antiwear and tackiness properties
|
Extended gear life, less downtime and reduced maintenance and replacement cost
|
|
Avoids potential for solvent retention and reduced viscosity with solvent-type products
|
|
Provides much thicker EHL film compared with semi-fluid grease products
|
Excellent pumpability at ambient temperatures
|
Reduction in pump replacement costs
|
Uses existing lubricant spray equipment
|
Low-cost conversion from asphaltic of semi-fluid grease products
|
Lower application rates than greases, less waste compared with asphalt/solvent products
|
Reduced lubricant consumption and disposal costs
|
Does not contain solids or asphaltic resins
|
Absence of hard-packed gear root deposits results in reduction in downtime and maintenance costs
|
Light coloured product
|
Avoids need for costly gear cleaning prior to inspection
|
Solvent-free
|
Improved safety through absence of solvent
|
Applications
Application Considerations: Normally, conversion to Mobilgear SHC 22M or 46M from asphaltic or grease products will be a simple process with no change in lubricant spray equipment. It is recommended that the gears be thoroughly cleaned to take advantage of the light colour of these synthetic products. Consult your Mobil representative for further details on lubricant conversion.
Mobilgear SHC 22M and 46M are designed specifically for use in heavily loaded, low speed open gearing which drive stationary rotating machinery. Product application is by spray nozzle systems. Specific applications include:
-
Kilns and mills in metal mining, cement and limestone production and in sugar plants
-
Slow speed, heavily loaded plain and rolling contact bearings
Typical Properties
Mobilgear SHC
|
22M
|
46M
|
ISO Viscosity Grade
|
|
|
Viscosity, ASTM D 445
|
|
|
cSt @ 40o C
|
22,000
|
46,000
|
cSt @ 100o C
|
700
|
1375
|
Viscosity Index, ASTM D 2270
|
180
|
180
|
Pour Point, oC, ASTM D 97
|
6
|
15
|
Flash Point, oC, ASTM D 92
|
240
|
240
|
Specific Gravity @15.6o C kg/l, ASTM D 4052
|
0.89
|
0.924
|
Rust Test, ASTM D 665 B, Sea Water
|
Pass
|
Pass
|
Copper Strip Corrosion, ASTM D 130,3 hrs @ 100o C
|
1B
|
1B
|
 |
