美孚?SHC 600系列

卓越的性能齒輪和軸承油

產品描述

美孚?SHC 600系列潤滑油是性能卓越的齒輪和軸承油設計提供在設備保護方面的卓越服務，油品壽命及無故障操作幫助提高客戶的生產效率。這些科學設計的油是采用最新的專利和正在申請專利的美孚公司技術提供卓越和平衡要求在高溫和低溫條件下的應用程序的性能制定。美孚油600產品具有良好的低溫性能，以及改進的空氣釋放性能在低粘度等級。這些產品是耐機械剪切，即使在重負荷齒輪和高剪切軸承的應用，使幾乎沒有損失的粘度。

美孚SHC 600系列產品具有低牽引系數相對于礦物油來自基礎油的分子結構的應用。這一結果在低流體摩擦對不合格的表面如齒輪和滾動接觸軸承負荷區。低流體摩擦產生較低的工作溫度和提高齒輪效率，這轉化為降低功耗。美孚SHC 600系列產品已證明3.6%在受控的實驗室測試在提高能源效率（*）。美孚SHC 600系列配方還提供優異的耐氧化和高溫沉積物的形成，以及優異的抗銹蝕和腐蝕、抗磨、抗乳化性、泡沫控制和空氣釋放性，與多種金屬相容。美孚SHC 600系列潤滑油保持與通常使用的設備潤滑油與礦物油密封和其他材料相容性好。

應用
而美孚SHC 600系列一般都是以礦物油為基礎的產品兼容，摻用可能減弱其性能。因此建議改變系統的一個美孚SHC 600系列產品之前，應徹底清洗和沖洗，以達到最大的性能效益。美孚SHC 600系列潤滑油是最NBR相容，氟橡膠和其他橡膠密封材料，用礦物油。有潛在的大幅變化的彈性體。為了獲得最佳效果，請咨詢您的設備供應商、密封制造商或您的本地公司代表來驗證兼容性。
美孚SHC 600系列潤滑油推薦用于各種齒輪和軸承應用在高或低的溫度中或在工作溫度或散裝油溫度等常規潤滑油給生活中的不如意，或者提高效率所需的。它們是特別有效的，在應用中的組件更換的維護成本，系統清洗和潤滑劑的變化是很高的。特定的應用程序需要選擇適當?shù)恼扯鹊燃?jí)，并包括：
對生命的變速箱填充，特別是高率/低效率的蝸輪
位于遠程的變速箱，其中石油改變是困難的
低溫應用，如滑雪升降機，季節性的石油的變化是可以避免的
遇到高溫時，混合輥軸承和輥頸軸承
塑料壓延機
嚴重的離心機的應用，包括船用離心機
鐵路A / C牽引傳動
美孚SHC 626、627、629和630的適合噴油螺桿壓縮機壓縮天然氣、油田氣聚集，二氧化碳和其他氣體的過程中使用的天然氣行業
美孚油629，630，632，634，636，和639是由西門子公司在Flender上市的變速箱

Mobil SHC? 600 Series

Exceptional Performance Gear and Bearing Oils

Product Description

Mobil SHC? 600 Series lubricants are exceptional performance gear and bearing oils designed to provide outstanding service in terms of equipment protection, oil life and problem-free operation helping to enable increased customer productivity. These scientifically engineered oils are formulated using the latest proprietary and patent pending Mobil SHC technology to provide outstanding and balanced performance in demanding applications at high and low temperatures. Mobil SHC 600 products feature excellent low temperature properties, as well as improved air release performance in the lower viscosity grades. These products are resistant to mechanical shear, even in heavily loaded gear and high shear bearing applications, so that there is virtually no loss of viscosity.
Mobil SHC 600 Series products have low traction coefficients relative to mineral oils which derive from the molecular structure of the base stocks used. This results in low fluid friction in the load zone of non-conforming surfaces such as gears and rolling contact bearings. Low fluid friction produces lower operating temperatures and improved gear efficiency, which translates into reduced power consumption. Mobil SHC 600 Series products have demonstrated up to 3.6% improvement in energy efficiency in controlled laboratory testing(*). Mobil SHC 600 Series formulation also provides excellent resistance to oxidation and deposit formation at elevated temperatures, as well as exceptional resistance to rusting and corrosion, antiwear, demulsibility, foam control and air release properties, and multi-metal compatibility. Mobil SHC 600 Series oils maintain good compatibility with seals and other materials used in equipment normally lubricated with mineral oils.
Mobil SHC 600 Series lubricants are suitable for use in a wide range of equipment, not only as high temperature problem solvers, but also because of the other benefits they offer.

(*) Energy efficiency relates solely to the performance of Mobil SHC 600 when compared to conventional (mineral) reference oils of the same viscosity grade in circulating and gear applications. The technology used allows up to 3.6% efficiency compared to the reference when tested in a worm gearbox under controlled conditions. Efficiency improvements will vary based on operating conditions and application.

Features and Benefits

The Mobil SHC brand of lubricants are recognized and appreciated around the world for their innovation and outstanding performance. These synthetic products, molecularly designed and pioneered by our research scientists, embody the continuing commitment to using advanced technology to provide outstanding lubricant products. The development of Mobil SHC 600 Series was preceded by close contacts between our scientists and application specialists with key Original Equipment Manufacturers (OEMs) to ensure that the products provide exceptional performance in the continually evolving industrial equipment designs.
Our work with key equipment builders has helped confirm the results from our own laboratory and rig tests showing the exceptional performance of Mobil SHC 600 Series lubricants. Not least among the benefits, shown in work with OEMs, is the potential for energy efficiency improvements up to 3.6% relative to mineral oils (*). These benefits are particularly evident in equipment with a high level of mechanical losses, such as high ratio worm gears.
To develop the latest Mobil SHC technology for Mobil SHC 600 Series oils, our product formulation scientists chose select base oils because of their exceptional thermal/oxidative resistance potential and combined them with a balanced additive system, which complements the inherent benefits of the base oils to provide excellent oil life, deposit control and resistance to thermal/oxidative and chemical degradation. This formulation approach provides low temperature fluidity characteristics exceeding that of many conventional mineral products and is a key benefit for remote, low ambient temperature applications. Mobil SHC 600 Series oils offer the following features and potential benefits:

(*) Energy efficiency relates solely to the performance of Mobil SHC 600 when compared to conventional (mineral) reference oils of the same viscosity grade in circulating and gear applications. The technology used allows up to 3.6% efficiency compared to the reference when tested in a worm gearbox under controlled conditions. Efficiency improvements will vary based on operating conditions and application.

Applications

While Mobil SHC 600 Series are generally compatible with mineral oil based products, admixture may detract from their performance. Consequently it is recommended that before changing a system to one of Mobil SHC 600 Series products, it should be thoroughly cleaned out and flushed to achieve the maximum performance benefits. Mobil SHC 600 Series oils are compatible with most NBR, FKM and most other elastomeric seal materials that are used with mineral oils. There is the potential for substantial variations in the elastomers. For best results, consult your equipment supplier, seal manufacturer, or your local company representative to verify compatibility.
Mobil SHC 600 Series lubricants are recommended for use in a wide variety of gear and bearing applications where high or low temperatures are encountered or where operating temperatures or bulk oil temperatures are such that conventional lubricants give unsatisfactory life, or where improved efficiency is desired. They are particularly effective in applications where the maintenance costs of component replacement, system cleaning and lubricant changes are high. Specific applications require selection of the appropriate viscosity grade and include:

• Filled for life gearboxes, especially high ratio/ low-efficiency worm gears
• Remotely located gearboxes, where oil change-out is difficult
• Low temperature applications, such as ski lifts where seasonal oil changes can be avoided
• Mixer roll bearings and roll neck bearings where high temperatures are encountered
• Plastic calenders
• Severe centrifuge applications, including marine centrifuges
• Railroad A/C Traction Drives
• Mobil SHC 626, 627, 629 and 630 are suitable for Oil Flooded Rotary Screw Compressors compressing natural gas, field gas gathering, CO2 and other process gasses used in the natural gas industry
• Mobil SHC 629, 630, 632, 634, 636, and 639 are approved by Siemens AG for use in Flender gearboxes

Specifications and Approvals

Typical Properties
