美孚 SHC?潤滑脂 460 WT
風力發電機高性能合成潤滑脂
產品簡介
美孚 SHC? 潤滑脂 460 WT是一種高性能的優質潤滑劑，尤其適用于風力發電機在極端溫度環境中運行的嚴苛要求。 本產品采用獨特配方，以合成基礎油加上高質量復合鋰皂基配制而成。 合成基礎油的無蠟性質和低牽引系數提供出色的低溫泵送性和很低的起動及運轉扭矩。 復合鋰皂基則提供出色的粘附性、結構穩定性和抗水性。 該潤滑脂具有高度的化學穩定性，采用特殊的添加劑組合配方，在高溫和低溫條件下提供出色的防磨損、防銹和防腐蝕保護。
美孚 SHC 潤滑脂 460 WT經特別配方調制，專門用于潤滑風力發電機偏航系統、變漿系統及主軸承的潤滑，已成為許多風力發電機制造廠和部件供應商用于初裝的首選產品。 本產品因其優秀的質量和可靠性而享有出色的聲譽，在全世界超過10,000臺風力發電機的成功應用，證明了其卓越的性能。
特性與優點
美孚 SHC? 品牌潤滑油和潤滑脂的創新配方和杰出性能在全世界得到公認。 ?？松梨诋a(chǎn)品開發中的一個關鍵因素是與主要原始設備制造商(OEM) 建立密切合作，保證產品在面對不斷發展的工業設備設計而具有出色的性能。
為了適應嚴酷的應用條件， 美孚 SHC 潤滑脂 460 WT選用本公司專有的具有出色的抗熱和抗氧化能力的合成基礎油。。 先進的復合鋰基增稠劑技術和特種添加劑有助于強化美孚 SHC 潤滑脂 460 WT性能，提供以下優點和特性：
|
特性
|
優點及潛在效益
|
|
與常規潤滑脂相比，具有卓越的高溫和低溫性能
|
應用溫度范圍廣，在高溫條件下提供出色的保護，在低溫時啟動扭矩低易于起動。
|
|
與常規潤滑脂相比，具有杰出的熱穩定性和抗氧化性
|
使用壽命長，從而延長潤滑周期，提高軸承壽命。
|
|
出色的抗磨、防銹和防腐保護
|
減少停機時間和養護成本
|
|
出色的泵送性
|
對采用集中供脂系統或潤滑脂加注器的軸承提供可靠的潤滑
|
|
在有水的使用條件下具有出色的結構穩定性
|
在嚴重的有水環境中保持出色的潤滑脂性能
|
|
牽引系數低
|
與常規潤滑脂相比，合成配方具有提高機械壽命和降低能源成本的潛力
|
應用
美孚 SHC 潤滑脂 460 WT是一種 NLGI 1.5級的極壓潤滑脂，采用 ISO VG 460 合成基礎油，適用于在嚴苛環境中運行的風力發電機。 該產品對重負荷的，在低速至中速運行并必須勝任耐水作業的軸承提供出色的保護。 美孚 SHC 潤滑脂 460 WT符合大多數風力發電機制造廠及部件供應商的規格。無論是手工涂脂或采用集中供脂系統或潤滑脂加注器，該產品對偏航、變漿和主軸承的潤滑均呈現出色的性能。 推薦作業溫度范圍為-30o C至 150oC。
Mobil SHC? Grease 460 WT
High Performance Synthetic Grease for Wind Turbines
Product Description
Mobil SHC? Grease 460 WT is a superior performance lubricant especially suited to exceed the demanding requirements of wind turbine applications at extremes of temperature. The unique features of synthetic base fluids are combined with those of a high quality lithium complex thickener. The wax-free nature of synthetic fluids and the low coefficient of traction provide excellent low temperature pumpability and very low starting and running torque. The lithium complex thickener contributes excellent adhesion, structural stability and resistance to water. The grease has a high level of chemical stability and is formulated with special additive combinations to provide excellent protection against wear, rust and corrosion at high and low temperatures.
Mobil SHC Grease 460 WT is specially formulated to lubricate yaw, pitch and main bearings of wind turbines and has become the first fill product of choice for many wind turbine builders and component suppliers. The reputation is based on its exceptional quality and reliability and has proven outstanding performance in more than 10,000 wind turbines worldwide.
Features and Benefits
The Mobil SHC? brand of oils and greases are recognized and appreciated around the world for their innovation and outstanding performance. A key factor in the development of ExxonMobil′s products was the close contacts with key Original Equipment Manufacturers (OEMs) to ensure that our product offerings would provide exceptional performance in the continually evolving industrial equipment designs.
Our work with equipment builders has helped confirm the results from our own laboratory tests showing the exceptional performance of Mobil SHC Grease 460 WT. Compared to conventional greases the benefits of this synthetic grease include longer grease life, enhanced false brinelling protection and bearing life, wide temperature range of application, and the potential for improved mechanical efficiency.
To combat severe application conditions proprietary synthetic base oils have been chosen for Mobil SHC Grease 460 WT because of their outstanding thermal/oxidative resistance potential. A state-of-the-art lithium complex thickener technology and specific additives help to enhance the performance of Mobil SHC Grease 460 WT offering the following features and benefits:
|
Features
|
Advantages and Potential Benefits
|
|
Outstanding high temperature and low temperature performance compared to conventional greases
|
Wide application temperature ranges, with excellent protection at high temperatures and low torque, easy start-up at low temperatures
|
|
Superb thermal stability and oxidation resistance compared to conventional greases
|
Extended service life with longer intervals between relubrication and improved bearing life
|
|
Excellent protection against wear, rust and corrosion
|
Reduced downtime and maintenance costs
|
|
Excellent pumpability
|
Reliable lubrication of bearings using centralized grease systems or grease dispensers
|
|
Outstanding structural stability in the presence of water
|
Retains excellent grease performance in hostile aqueous environment
|
|
Low traction coefficient
|
Synthetic formulation delivers potential improved mechanical life and reduced energy costs versus conventional greases
|
Applications
Mobil SHC Grease 460 WT is an NLGI 1.5 Grade extreme pressure grease with ISO VG 460 synthetic base fluid recommended for tough wind turbine applications. It provides outstanding bearing protection under heavy loads at low-to-moderate speeds and in applications where water resistance is a critical factor. Mobil SHC Grease 460 WT meets most specifications of wind turbine builder and component suppliers and has demonstrated outstanding performance in applications such as lubrication of yaw, pitch and main bearings either manual greased or using centralized grease systems or grease dispensers. The recommended operating temperature range is -30o C to 150oC.
Specifications and Approvals
|
Mobil SHC Grease 460 WT meets or exceeds the requirements of:
|
|
|
DIN 51825: (2004-06)
|
KPHC1-2N-30
|
Typical Properties
|
|
Mobil SHC Grease 460 WT
|
|
NLGI Grade
|
1.5
|
|
Thickener Type
|
Lithium Complex
|
|
Colour, Visual
|
Red
|
|
Penetration, Worked, 25oC, ASTM D 217
|
305
|
|
Dropping Point, oC, ASTM D 2265
|
255
|
|
Viscosity of Oil, ASTM D 445 cSt @ 40oC
|
460
|
|
Timken OK Load, ASTM D 2509, lb.
|
55
|
|
4-Ball Weld, ASTM D 2596, Load, Kg
|
250
|
|
Water Washout, ASTM D 1264, Loss at 79oC. % wt
|
10
|
|
Rust Protection, ASTM D 6138, Distilled Water
|
0,0
|
|
Corrosion Protection, ASTM D 1743, Rating
|
Pass
|
Health and Safety
Based on available information, this product is not expected to produce adverse effects on health when used for the intended application and the recommendations provided in the Material Safety Data Sheet (MSDS) are followed. MSDS's are available upon request through your sales contact office, or via the Internet. This product should not be used for purposes other than its intended use. If disposing of used product, take care to protect the environment.
The Mobil logotype, the Pegasus design, Mobil SHC (and any other trademarks) are trademarks of Exxon Mobil Corporation, or one of its subsidiaries.
1-2016
 |
