Mobil SHC Gear 150,220.320,460，680，1000
美孚齒輪油SHC系列齒輪油
產品描述
美孚齒輪油SHC?系列潤滑油是性能卓越的重負荷齒輪油，供所有類型的密封式齒輪裝置以及滑動與滾動元件軸承使用。 他們的目的是在設備保護，油品壽命及無故障操作等使客戶提高生產力方面提供優質的服務。 這些科學設計的合成潤滑油是由具有卓越的抗氧化性能和熱性能和優異的低溫流動性的合成基礎油配制。 固有的高粘度指數和獨特的添加劑配方結合，使本系列產品在嚴苛的高，低溫工作條件下表現杰出。 合成基礎油的本質，也有助于產品具有優異的低溫性能。 它們具有杰出的極壓性，并能承受沖擊負荷。
合成基礎油有導致不符合要求的表面，如齒輪和滾動元件軸承負荷區的流體低摩擦固有的低牽引力特性。 流體摩擦降低，可降低工作溫度，提高齒輪的效率。
美孚齒輪油SHC系列涵蓋了非常廣泛的粘度范圍，介于ISO VG 150至6800之間。
因此，他們發現應用在廣泛的閉式齒輪的應用，以及滑動與滾動元件軸承使用。 由于具有粘度等級高的，這個家庭能滿足的很慢的速度和高負荷/高溫工作的齒輪和軸承的潤滑需求，它們是理想的，其中常規產品在邊界制度的運作情況。 它們可以是其中的潤滑劑浴或recirulation系統被用于施加油的情況。
美孚齒輪油SHC系列潤滑油是首選產品，為全球范圍內基于其廣泛的應用范圍和精湛的表演在艱難的情況下，許多原始設備制造商和客戶。
Mobil SHC? Gear Series
Gear Oils
Product Description
Mobil SHC? Gear Series is a line of exceptional performance, synthetic industrial gear oils designed to provide outstanding protection of gears and bearings, extended oil life even under extreme conditions, helping to enable problem-free operation of equipment and increased customer productivity. These scientifically engineered synthetic lubricants are formulated from synthetic base fluids that have exceptional oxidation and thermal properties and excellent low temperature fluidity. The high viscosity index of these oils deliver less change in viscosity with changes in temperature, enabling wider operating temperature range and improved low temperature startup. Mobil SHC Gear Series lubricants contain an advanced proprietary additive system designed to provide excellent protection against conventional wear modes such as scuffing as well as a high level of resistance against micropitting fatigue. In addition, compared to conventional gear oil chemistries, it offers the potential for improved lubrication of gearbox rolling element bearings. Mobil SHC Gear Series products offer outstanding rust and corrosion protection relative to conventional gear oils, even in the presence of seawater contamination. They show no tendency to plug fine filters even when wet and have excellent compatibility with ferrous and non-ferrous metals even at elevated temperatures. Mobil SHC Gear Series also exhibit outstanding compatibility with elastomers in static seal tests. They have outstanding EP properties that provide protection even under shock load conditions. The synthetic base stocks used in Mobil SHC Gear Series oils have inherently low traction properties that result in low fluid friction in the load zone of non-conforming surfaces such as gears and rolling element bearings. Reduced fluid friction produces lower operating temperatures and can help improve gear efficiency.
Mobil SHC Gear lubricants are recommended for enclosed industrial gear drives including steel-on-steel spur, helical, and bevel gears. They are especially recommended for applications that may be subject to micropitting: especially heavily loaded gearboxes with surface-hardened tooth metallurgies. It may also be used in gear applications where extreme low and/or high temperatures are encountered and applications where corrosion may be severe.
Features and Benefits
Mobil SHC Gear Series lubricants are part of the Mobil SHC line of products that are recognized and appreciated around the world for innovation and outstanding performance. These synthetic products, pioneered by our research scientists, symbolize the continuing commitment to using advanced technology to provide lubricants with excellent balanced performance. A key factor in the development of Mobil SHC Gear Series was the close contacts between our scientists and application specialists with key OEMs to ensure that our product offering would provide exceptional performance with rapidly evolving industrial gear designs and operation. Not least among the benefits shown in work with OEMs is the ability to resist micropitting wear which can occur with some highly loaded, case-hardened gearing applications. This cooperative work also demonstrated the all-round balanced performance benefits for the new Mobil SHC Gear technology, including a wide temperature range of application.
To address the issue of micropitting wear, our product formulation scientists designed a proprietary combination of additives which would resist traditional gear wear mechanisms as well as protecting against micropitting. Mobil SHC Gear products provide exceptional oil life and deposit control and resistance to thermal/oxidative and chemical degradation, as well as the balance of the performance features. The patent-pending combination of synthetic base oils also provides exceptional low temperature fluidity characteristics unmatched by conventional mineral oil gear lubricants and is a key benefit for remote, low ambient temperature applications. The Mobil SHC Gear Series lubricants offer the following potential benefits:
|
Features
|
Advantages and Potential Benefits
|
|
Superb protection from micropitting fatigue wear as well as high resistance to traditional scuffing wear
|
Helps extend gear and bearing life in enclosed gear drives operating under extreme conditions of load, speed and temperature
Helps reduce unplanned downtime; less maintenance - especially critical for difficult to access gearboxes.
|
|
Excellent resistance to degradation at high temperatures
|
Helps extend oil life and drain intervals and reduce oil consumption, which can lower maintenance costs
|
|
Low traction
|
Helps reduce energy consumption and lower operating temperatures
|
|
High viscosity index equating to reduced viscosity change with temperature
|
Ability to operate at both high and low temperatures: especially critical in remote applications with no oil cooling or heating
|
|
Excellent resistance to rust and corrosion and very good demulsibility
|
Helps to ensure smooth, trouble-free operation at high temperatures or in applications subject to water contamination
Excellent compatibility with a variety of soft metals
|
|
Excellent shear stability
|
Helps extend gear and bearing life
|
|
Resistence to filter plugging, even in the presence of water
|
Fewer filter changes; which can help reduce maintenance costs
|
|
Excellent seal compatibility
|
Less contamination and lower potential for oil leakage
|
|
Excellent compatibility with common gearbox materials and with mineral-based gear oils
|
Easy changeover from many mineral products
|
Applications
Application Considerations: While the Mobil SHC Gear Series are compatible with mineral oil based products, admixture may detract from their performance. Consequently it is recommended that before changing a system to one of the Mobil SHC Gear Series, it should be thoroughly cleaned out and flushed to achieve the maximum performance benefits.
Mobil SHC Gear Series exceptional performance, synthetic industrial gear oils are designed to provide optimum equipment protection and oil life even under extreme conditions. They are especially formulated to resist micropitting of modern, case hardened gearing and can operate in both high and low temperature environments. Typical applications include:
-
Modern, highly loaded gearboxes used in the paper, steel, oil, textile, lumber and cement industries where gear protection and optimum oil life are required.
-
Plastic extruder gearboxes
Mobil SHC Gear Series ISO VG 150, 220, 320, 460 and 680 are approved under General Electric’s (GE) gear oil specification D50E35 for use in off-highway vehicle motorized wheel gearbox applications.
Specifications and Approvals
|
Mobil SHC Gear meets or exceeds the following industry specifications
|
150
|
220
|
320
|
460
|
680
|
1000
|
|
Meets AGMA 9005-E02
|
X
|
X
|
X
|
X
|
X
|
X
|
|
Meets DIN 51517 Part 3 (CLP)
|
X
|
X
|
X
|
X
|
X
|
X
|
|
Meets ISO 12925-1 Type CKD
|
X
|
X
|
X
|
X
|
X
|
|
|
Meets ISO 12925-1 Type CKT
|
X
|
X
|
|
|
|
|
|
Mobil SHC Gear has the following builder approvals
|
150
|
220
|
320
|
460
|
680
|
1000
|
|
SIEMENS AG Flender gear units, T 7300, Table A-c, Flender Code No.
|
A36
|
A35
|
A34
|
A33
|
A32
|
A31
|
SEW Eurodrive
SEW IG CLP HC
|
150
|
220
|
320
|
460
|
680
|
1000
|
|
GE Motorized Wheel
|
D50E35
|
D50E35
|
D50E35
|
D50E35
|
D50E35
|
D50E35
|
Typical Properties
|
Mobil SHC Gear Series
|
150
|
220
|
320
|
460
|
680
|
1000
|
|
ISO Viscosity Grade
|
150
|
220
|
320
|
460
|
680
|
1000
|
|
Viscosity, ASTM D 445
|
|
|
|
|
|
|
|
cSt @ 40oC
|
150
|
220
|
320
|
460
|
680
|
1000
|
|
cSt @ 100oC
|
22.2
|
30.4
|
40.6
|
54.1
|
75.5
|
99.4
|
|
Viscosity Index, ASTM D 2270
|
176
|
180
|
181
|
184
|
192
|
192
|
|
Pour Point, oC, ASTM D 97
|
-45
|
-39
|
-33
|
-27
|
-27
|
-24
|
|
Flash Point, oC, ASTM D 92
|
233
|
233
|
233
|
234
|
234
|
234
|
|
Brookfield @ 0oF (-18oC), cP, ASTM D 2983
|
|
|
|
|
41000
|
96000
|
|
Brookfield @ -20oF (-28oC), cP, ASTM D 2983
|
18200
|
35000
|
57000
|
107000
|
156000
|
500000
|
|
Density 60oF (15,6oC), g/ml
|
0.86
|
0.86
|
0.86
|
0.86
|
0.86
|
0.87
|
|
Total Acid Number, mg KOH/g, ASTM D 664
|
0.9
|
0.9
|
0.9
|
0.9
|
0.9
|
0.9
|
|
4 Ball EP Test, kgf, ASTM D 2783
|
|
|
|
|
|
|
|
Weld Load
|
200
|
200
|
200
|
200
|
200
|
200
|
|
Load Wear Index
|
51
|
51
|
51
|
51
|
51
|
51
|
|
FZG Micropitting, FVA Proc No. 54, 90°C
|
|
|
|
|
|
|
|
Fail Stage
|
10
|
10
|
10
|
10
|
10
|
10
|
|
GFT-Class
|
High
|
High
|
High
|
High
|
High
|
High
|
|
FZG Scuffing, ISO 14635-1 (mod) A/8.3/90, Fail Stage
|
13
|
14
|
14
|
14
|
14
|
14
|
|
FZG Scuffing, ISO 14635-1 (mod) A/16.6/90, Fail Stage
|
Not tested
|
>14
|
>14
|
>14
|
>14
|
>14
|
|
Copper Corrosion, 3H @ 121°C, ASTM D 130
|
1B
|
1B
|
1B
|
1B
|
1B
|
1B
|
|
Rust protection, ASTM D665, Sea Water
|
Pass
|
Pass
|
Pass
|
Pass
|
Pass
|
Pass
|
|
Demulsibility of EP Oils, Free Water, ml, ASTM D 2711
|
88
|
87
|
85
|
84
|
87
|
|
|
Water Separability, ASTM D 1401,Time to 40/37/3 at 82oC, minutes
|
10
|
10
|
10
|
15
|
25
|
40
|
|
Foaming Characteristics, ASTM D 892,Seq. II, Tendency/Stability, ml/ml
|
0/0
|
0/0
|
0/0
|
20/0
|
0/0
|
0/0
|
 |
