Mobiltherm 600系列
傳熱油
產品描述
傳熱油Mobiltherm高性能產品用于閉式間接加熱裝置。建議在各種工業(yè)過程中使用的冷油密封，間接加熱和冷卻系統(tǒng)。
傳熱油Mobiltherm制定由高度精煉的基礎股票是抵抗熱裂化和化學氧化。他們是非常熱穩(wěn)定，是一個非常長的使用壽命沒有存款的形成或粘度增加的能力。
傳熱油Mobiltherm有良好的傳熱效率和粘度等，可以抽容易在啟動和運行溫度。他們表現(xiàn)出比熱和熱導率，提供更快速的散熱。這些油的閃光點不會減少顯著的服務，因為他們的抵抗熱裂紋的工作溫度，他們的建議。

Mobiltherm 600 Series

Heat transfer Oils

Product Description

Mobiltherm heat transfer oils are high performance products intended for use in closed indirect heating installations. They are recommended for use in cold-oil sealed, indirect heating and cooling systems in all kinds of industrial processes.

Mobiltherm heat transfer oils are formulated from highly refined base stocks that are resistant to thermal cracking and chemical oxidation. They are very thermally stable and are capable of an extremely long service life without deposit formation or viscosity increase.

Mobiltherm heat transfer oils have good heat transfer efficiency and their viscosities are such that they can be pumped readily at both start-up and operating temperatures. They demonstrate specific heat and thermal conductivities that provide more rapid heat dissipation. The flash points of these oils will not decrease significantly in service because of their resistance to thermal cracking at the operating temperatures for which they are recommended.

Features and Benefits

Mobiltherm oils are important members of the Mobil brand of specialty fluids that have gained a reputation for performance and reliability, even in severe applications. Modern refining techniques are a key factor in providing the excellent product features.

Mobiltherm 600 Series offer the following benefits:

Applications

Application Considerations: Mobiltherm heat transfer oils should not be mixed with other oils since this may impair the excellent thermal and oxidation stability resulting in a change in other properties, and complicate analyses aimed at determining useful oil life. If the oils are used above their recommended maximum temperatures, vapor lock may result unless the system is designed to operate at the higher temperature by pressurizing with an inert gas such as nitrogen. At higher temperatures, fluid life will be shortened because the rate of thermal degradation which increases markedly as temperatures rise above the recommended limit. In well-designed systems the temperature of the oil film surrounding the heating element should be about 15oC to 30oC above the bulk oil temperature. If higher than this, the service life of the oil may be shortened and sludge and coke may be deposited which would interfere with the heat transfer rates.

As with other mineral oils, Mobiltherm heat transfer oils should be used only in systems with forced circulation. Systems that depend on convection for circulation of the heat transfer medium do not provide a rapid enough flow to prevent local overheating and rapid deterioration of the oil. Further, these oils are not recommended for use in open systems where hot oil is exposed directly to the air. If they spray or escape from leakage points, hot Mobiltherm oils may spontaneously ignite.

Mobiltherm 600 series can be used in open and closed installations where the bulk oil temperature ranges are as outlined in the table below.

• Mobiltherm 603: Closed Systems (-15o C to 285o C), Open Systems (-15o C7 C to 150o C)
• Mobiltherm 605: Closed Systems (-12o C to 315o C), Open Systems (-12o C to 180o C)
• Mobiltherm 610: Open systems (-6°C to 250°C)
• Mobiltherm 611: Open systems (-6°C to 275°C)

Typical Properties
