Mobil Vacmul EDM 3多用途電火花加工液
產品描述
Vacmul電火花加工油是多用途的絕緣液用于所有電火花加工機床正常工作的滲透尤其適用于粗加工，精加工和超精加工工作。 Vacmul電火花加工是專為最高的機器生產率和操作員舒適性的電，放電加工中使用時，也稱為電火花腐蝕加工非常純凈的液體。
在這個過程中金屬加工金屬是從一工件施加在工件和成形電極之間的電位差去除。 Vacmul電火花具有提供均勻的絕緣，然后在擊穿電壓，以允許控制電極放電的能力。
Vacmul電火花具有粘性，波動性，氧化安定性，熱傳導特性，低氣味，低毒性的正確平衡。 Vacmul電火花加工是一種高度精煉，窄餾分，低粘度流體特別適合于精加工工序，其中一個高品質的完成是必需的。
它的功能是刀具和工件，火花導體，冷卻液和沖洗油排屑之間的絕緣體。 Vacmul電火花推薦用于高金屬去除率是必需的粗加工和精加工和超精加工工作。
特點和優點
優點及潛在效益
1 限制火災風險
2 產量增加
3 確保液體/金屬接觸和減少廢品
4 方便查看工件和夾具
5 易于處理和改善車間環境
6 較高的金屬去除速率和穩定的電氣放電
7 提供均勻的絕緣，更高的精度和表面光潔度
產品特點
1 高閃點
2 通過墨盒和地球極好的過濾
3 高潤濕性
4 明亮，干凈，無臭。
5 在正常使用低敏感性皮膚
6 非脂肪相比，更粘稠液體。
應用
1 優秀的通過滲透工作的所有電火花機。
2 特別適用于粗加工，精加工和超精加工工作。
美孚Mobil Vacmul EDM 2電火花加工液Mobil Vacmul EDM 3
Vacmul EDM 2 and 3
Multipurpose Electro Discharge Machining Fluids
Product Description
Vacmul EDM fluids are multipurpose dielectric fluids for use in all discharge machines working by penetration especially for roughing, finishing and superfinishing work. Vacmul EDM is very pure fluid designed for maximum machine productivity and operator comfort when used in electrical-discharge machining, also called spark-erosion machining. In this metalworking process metal is removed from a workpiece by applying a potential difference between the workpiece and a shaped electrode. Vacmul EDM has the ability to provide uniform insulation and then to permit controlled electrical discharge at the breakdown voltage.
Vacmul EDM has the correct balance of viscosity, volatility, oxidation stability, heat transfer characteristics, low odour and low toxicity. Vacmul EDM is a highly refined, narrow-cut, low viscosity fluid specially suited to finishing operations where a high quality finish is required. It functions as an insulator between tool and workpiece, spark conductor, coolant and as a flushing oil for chip removal. Vacmul EDM is recommended for roughing operations where a high metal removal rate is required and for finishing and superfinishing work.
Features and Benefits
|
Features
|
Advantages and Potential Benefits
|
|
High flash point
|
Limits fire risk
|
|
Excellent filterability through cartridge and earth
|
Increased production
|
|
High wetability
|
Ensures liquid / metal contact and fewer rejects
|
|
Bright, clean and odourless.
|
Easy viewing of work piece and fixtures
|
|
Low skin sensitivity in normal use
|
Easy handling and improved workshop environment
|
|
Non fatty compared to more viscous fluids.
|
Higher metal removal rate and stable electrical discharge
|
|
Good detergency with respect to small particles.
|
Provides uniform insulation, higher precision and surface finish
|
Applications
-
Excellent for all electro discharge machines that work by penetration.
-
Especially suitable for roughing, finishing and superfinishing work.
Typical Properties
|
Vacmul EDM
|
2
|
3
|
|
Density @ 15°C, kg/l ASTM D1298
|
0.791
|
0.799
|
|
Colour, Saybolt
|
+30
|
+30
|
|
Viscosity cSt at 40°C mm2/s ASTM D445
|
1.61
|
2.37
|
|
Flash Point, (P.M.) °C
|
83
|
108
|
|
IBP °C
|
207
|
243
|
|
FBP °C
|
227
|
272
|
|
Appearance
|
Clean and Bright
|
Clear and Bright
|
 |
